Informacje dodatkowe
Rodzaj produktu | 1 kanałowy BAE312A, 2 kanałowy BAE312A, moduł api 500 BAE312A |
---|
Rodzaj produktu | 1 kanałowy BAE312A, 2 kanałowy BAE312A, moduł api 500 BAE312A |
---|
312A Specifications
Frequency Response
5Hz to 75kHz (-3dB)
Mic Input Impedance
≈1400 ohms
Line Input Impedance
10k ohms
DI Input Impedance
≈250k ohms
Output Impedance
75 ohms
Common Mode Rejection Ratio
110dB min @ 60Hz
Maximum Output Level
+27.1 dBu @ 600Ω
Power Requirements
115/230 VAC, 27W (Rackmount)
40mA per Rail (Module)
Gain dB
10 to 66 dB
Equivalent Input Noise
-120 dBu; Unweighted 300kHz Bandwidth
Weight (Module/Rackmount)
1 LBS / 0.45 KG (Module)
7 LBS / 3.18 KG (Single Rackmount)
8 LBS / 3.63 KG (Dual Rackmount)
Dimensions in Inches (Rackmount/Module)
19W x 1.75L x 9D (Rackmount)
1.5W x 5.5L x 6D (Module)
